Square Tube Type Air Cylinder

Name: Square Tube Type Air Cylinder
Brand: HINDUSTAN HYDRAULICS & PNEUMATICS
Price: 500-100000 INR
Availability: InStock

Price 500-100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Square Tube Type Air Cylinder Specification

Pressure
0.1-1.0 MPa

Capacity
Customizable

Wall Thickness
Standard (as per size)

Temperature
-5C to +70C

Material
Aluminum Alloy

Structure
Square Tube

Power
Pneumatic

Dimensions
Standard/Custom sizes

Max. Stroke
Up to 1000 mm

Shaft Diameter
12 mm to 40 mm

Seals Type
Nitrile Rubber (NBR)

Rod
Single or Double Acting

Weight
Varies as per model

Port Size
M5, 1/8", 1/4" or as per model

Bore Size
16 mm to 100 mm

End Cap Material
Aluminum

Operating Medium
Filtered, Lubricated or Non-lubricated Air

Color
Silver with Black End Caps

Cushion Type
Bumper or Adjustable Air Cushion

Speed Range
50500 mm/sec

Mounting Type
Basic, Foot, Flange, or Custom

Application
Automotive, Industrial Automation, Packaging Machines

Repeatability
0.1 mm

Surface Finish
Anodized

Piston Rod Material
Carbon Steel, Chrome Plated

Square Tube Type Air Cylinder Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
2000 Pieces Per Day

Delivery Time
1 Week

Main Domestic Market
South India

About Square Tube Type Air Cylinder

Aluminum made Square Tube Type Air Cylinder has been designed as per ISO specifications. This pneumatically powered air cylinder can endure maximum 1.0 MPa operating pressure. This double action type product has maximum 1/8 inch port size and it can be used at up to 70 degree C operating temperature. The buffers of this product are located at their terminals and these buffers can be adjusted as per application needs. Threading specifications and mounting style of this Square Tube Type Air Cylinder depend on precise needs of customers.

Versatile Mounting Options

Choose from basic, foot, flange, or custom mounting types to suit your specific installation requirements. This adaptability supports easy integration into new or existing machinery, ensuring seamless compatibility across various industrial settings.

Superior Material and Surface Finish

Fabricated with a square tube aluminum alloy body, the cylinder features anodized silver surfaces paired with black end caps. The piston rod is carbon steel, chrome plated for longevity, while NBR seals ensure optimal air retention and minimal leakage.

High Precision and Customizability

Enjoy consistent accuracy with repeatability of 0.1 mm and a wide speed range (50500 mm/sec). With customizable bore, stroke, pressure, and port size options, these cylinders meet tailored capacity and dimensional requirements for demanding applications.

FAQs of Square Tube Type Air Cylinder:

Q: How do I select the appropriate mounting type for my application?

A: Select the mounting typebasic, foot, flange, or custombased on your equipment design and installation space. Consult with your supplier to ensure the chosen configuration integrates smoothly into your machinery and supports operational loads.

Q: What are the benefits of adjustable air cushions compared to bumper cushioning?

A: Adjustable air cushions provide smoother deceleration at the stroke end, reducing impact and prolonging component life. Bumper cushioning offers simple, economic end damping ideal for standard operations with moderate speeds and lighter loads.

Q: When should I use lubricated versus non-lubricated air as the operating medium?

A: Lubricated air is recommended for high-speed or continuous operation to reduce internal wear, while non-lubricated air suits environments where oil contamination must be avoided. Both require filtration to maintain cylinder performance and longevity.

Q: Where can these square tube air cylinders be applied most effectively?

A: They excel in automotive assembly lines, industrial automation systems, and packaging machinery, offering reliable actuation wherever linear movement and durability are critical.

Q: What is the process for customizing bore size, stroke, or port dimensions?

A: Customization begins with sharing your required specifications with the distributor or supplier. Engineering teams review and recommend feasible options, followed by tailored manufacturing once the design is approved.

Q: How does the anodized surface and chrome-plated piston rod improve cylinder performance?

A: The anodized aluminum surface protects against corrosion, while the chrome-plated carbon steel rod reduces friction and weartogether ensuring long service life and reliable operation even in demanding industrial conditions.
